SANG Solar Off Grid Solar System For Home 3.5KW 5.5KW 48V 220V 230V With 5kwh 10kwh 15kwh Lithium Battery

Name: SANG Solar Off Grid Solar System For Home 35KW 55KW 48V 220V 230V With 5kwh 10kwh 15kwh Lithium Battery
Brand: sangsolar
Price: 1 USD

Wholesale SANG Solar Off Grid Solar System For Home 3.5KW 5.5KW 48V 220V 230V With 5kwh 10kwh 15kwh Lithium Battery from china suppliers

Brand Name : sangsolar

Model Number : HP 20SA-solar system

Certification : CE

Place of Origin : Zhejiang,China

MOQ : 2

Price : Negotiated

Payment Terms : TT/LC/Alibabashop

Delivery Time : 15-30days

Packaging Details : 200*125*100(mm)

Output Power Range : 10~20 kwh

PV Maximum Input Power : 4000W/6000W

MPPT Voltage Range : 85~400V

Inverter Output Voltage : 220/230VAC3%

Output Frequency : 50-60HZ

Application : Home

Battery Type : Lithium Ion

System Type : Stackable

Work Time (h) : 24hours

Type : Split

Communication Port : RS485, RS232, CAN

Enclosure : IP20

Inverter Efficiency : ≥99.5%

Product name : MPPT Solar Hybrid Inverter 3.5KW 5.5KW

Output Voltage Waveform : Pure Sine Wave

Communication : RS485 with optional 4G, WiFi, or TCP modules

Contact Now

Product descriptions from the supplier

SANG Solar Off Grid Solar System For Home 3.5KW 5.5KW 48V 220V 230V With 5kwh 10kwh 15kwh Lithium Battery

EPEVER HP-AHP20SA Series 3500W 5500W

High Frequency Hybrid Solar Inverter With MPPT

SANG Solar Off Grid Solar System For Home 3.5KW 5.5KW 48V 220V 230V With 5kwh 10kwh 15kwh Lithium Battery

The HP-AHP20SA series is a cost-effective product. It supports multiple charging options, including utility, diesel generator, and solar. It is designed for utility bypass, inverter output, and energy management. The advanced DSP chip, along with its control algorithm, ensures rapid response times, reliability, and high conversion efficiency. Customers can efficiently utilize energy by flexibly switching between solar and utility power using customized settings.

Technical Specifications

Model		HP3542-AH0650P20SA	HP5542-AH1050P20SA
Utility input	Utility Voltage	176VAC~264VAC (Default), 90VAC~280VAC (Configurable)
	Utility Frequency	45Hz~65Hz
	Maximum Utility Charging Current	60A	100A
	Switch Response Time	Switch Response Time – Inverter to Utility: 10ms Switch Response Time – Utility to Inverter (when the load power is higher than 100W): 20ms
Inverter output	Inverter Rated Power (@30℃)	3500W	5000W
	3-second Transient Surge Output Power	7000W	8500W
	Inverter Output Voltage	220/230VAC±3%
	Inverter Frequency	50/60Hz±0.2%
	Output Voltage Waveform	Pure sine wave
	Load Power Factor	0.2~1(VA ≤ Rated output power)
	THDu (Total Harmonic Voltage Distortion)	≤3% (48V resistive load)
	Maximum Load Efficiency	92%
	Maximum Inverter Efficiency	94%
Solar controller	PV Maximum Open-circuit Voltage	500V (At minimum operating environment temperature) 440V (At 25℃)
	MPPT Voltage Range	85~400V
	PV Maximum Input Power	4000W	6000W
	PV Maximum Charging Current	60A	100A
	MPPT Maximum efficiency	≥99.5%
Battery	Battery Rated Voltage	48VDC
	Battery Work Voltage Range	43.2VDC~60VDC
	Battery Maximum Charging Current	60A	100A
Others	No-load Losses	＜0.7A	＜1.0A
		Test condition: No PV and utility, AC out is on, fan stops@48V input
	Standby Current	＜0.15A
		Test condition: No PV and utility, AC out is off, fan stops@48V input)
	Work Temperature Range	-20℃~+50℃ (When the environment temperature exceeds 30℃, the actual output power is reduced appropriately)
	Storage Temperature Range	-25℃~+60℃
	Enclosure	IP20
	Relative Humidity	< 95% (N.C.)
	Altitude	＜4000M (If the altitude exceeds 2000 meters, the actual output power is reduced appropriately)
Mechanical parameters	Dimension (Length x Width x Height)	534mm × 288mm × 163mm	590mm × 288mm × 163mm
	Mounting size (Length x Width)	512mm x 245mm	568mm x 245mm
	Mounting hole size	Φ9mm/Φ10mm	Φ9mm/Φ10mm
	Net Weight	12.0Kg	15.0Kg

SANG Solar Off Grid Solar System For Home 3.5KW 5.5KW 48V 220V 230V With 5kwh 10kwh 15kwh Lithium Battery

Products Description

SANG Solar Off Grid Solar System For Home 3.5KW 5.5KW 48V 220V 230V With 5kwh 10kwh 15kwh Lithium Battery
